This manual provides installation and operation instructions for the SCL/SCM Series Variable Frequency Drive. It covers input power terminals, output motor terminals, control terminal strip, 3-digit LED display, electronic programming module (EPM), and more. The manual also includes safety information and warnings to ensure proper operation and use of the drive.
This document is the official Installation and Operation Manual for the AC Tech SCL and SCM Series Variable Frequency Drives. It covers product descriptions, safety information regarding electrical hazards and static control, and general handling procedures.
The manual details the physical dimensions of various models based on input voltage (208/240V or 400/480V) and horsepower ratings. It also outlines warranty terms provided by AC Technology Corporation for a period of 24 months from shipment.
The product is warranted to be free of defects in material and workmanship for a period of 24 months from the date of shipment from AC Tech's factory.
The drive requires the use of minimum 75 °C copper wire only.
The drive shall be installed in a pollution degree 2 macro-environment.
