Lenze SMD drive is a fan drive used for air purification in laser cutting machines. It provides an economical and reliable means of precise speed control for the exhaust fan, allowing precise determination of air exhaust volume to clear smoke and maintain a clean laser area. The SMD drive has the advantages of cost-effectiveness, reliable operation, easy integration, high power capacity, and ease of use.
This manual provides the necessary information to install, wire, and operate the Lenze electric fan driver safely. It includes safety warnings, connection guidelines, and basic troubleshooting steps.
Technical data such as power rating, voltage, and physical dimensions are listed, allowing users to verify that the driver meets the requirements of their application.
| Power rating | 140.55 kW |
|---|---|
| Operating voltage | 240 V |
| Dimensions | 146 x 93 x 92 mm |
The fan driver is rated at 140.55 kW.
The device measures 146 mm × 93 mm × 92 mm.
