This manual provides information on parameter settings and configuration for the digital frequency extension module (E94AYFLF).
This document provides instructions on how to parameterize and configure the digital frequency extension module (Type EQ4AYFLF) for use with Lenze Servo Drives 9400. It serves as a companion to the Mounting Instructions and is valid in conjunction with Operating Instructions for standard devices.
The guide details procedures for setting up digital frequency inputs and outputs, including terminal assignments, signal form configuration, encoder detection, position scaling, and monitoring. It also explains how to use specific system blocks within the Lenze »Engineer« software for controlling these functions.
The documentation contains information on how to parameterise & configure the digital frequency extension module with the L-force »Engineer« and keypad.
The extension module can be used in conjunction with 9400 Servo Drives.
