This manual covers the AC Tech MC3000 Variable Frequency Drive
The document serves as a comprehensive guide for the AC Tech MC3000 Series Variable Frequency Drive. It covers product changes, warranty terms, receiving procedures, and customer modification policies. The manual is designed to assist users in understanding the drive's capabilities and limitations before installation.
Detailed technical specifications are provided, including operating temperature ranges, input voltage tolerances, output frequency limits, and efficiency ratings. The guide also explains how to interpret model designation codes to identify specific drive configurations based on horsepower, voltage, and enclosure type.
| Storage Temperature | -20° to 70° C |
|---|---|
| Ambient Operating Temperature (Chassis) | -10 ° to 55° C |
| Input Line Voltages | 240/120 Vac, 240/200 Vac, 480/400 Vac, and 590/480 Vac |
| Output Frequency | 0-120 Hz |
| Overload Current Capacity (60 seconds) | 150% of output rating |
| Efficiency | > 97% |
AC Technology Corporation warrants the product to be free of defects in material and workmanship for a period of two years from the date of shipment.
The output frequency ranges from 0 to 120 Hz.
No, AC Technology Corporation cannot assume responsibility for any modifications not authorized by its engineering department.
