The FDMS7658AS is a low-on-resistance switching device designed to minimize losses in power conversion applications. It combines advanced silicon and package technologies to offer the lowest rDS(on) while maintaining excellent switching performance. This device has the added benefit of an efficient monolithic Schottky body diode.
The FDMS7658AS is an N-Channel PowerTrench SyncFET designed to minimize losses in power conversion applications. It combines advancements in silicon and package technologies to offer low on-resistance while maintaining excellent switching performance. The device features an efficient monolithic Schottky body diode and is RoHS compliant.
| Drain to Source Voltage | 30 V |
|---|---|
| Continuous Drain Current (Package limited) | 49 A |
| Continuous Drain Current (Silicon limited) | 17 A |
| Power Dissipation (Tc = 25°C) | 89 W |
| Operating Junction Temperature Range | -55 to +150 °C |
| Thermal Resistance, Junction to Case | 1.4 °C/W |
| Static Drain to Source On Resistance (Typ) | 1.9 mΩ |
It is designed for synchronous rectification in DC/DC converters, notebook Vcore/GPU low side switching, networking point of load low side switching, and telecom secondary side rectification.
Yes, the device is RoHS compliant.
The maximum continuous drain current is 49 A when package limited at 25°C.
