This document introduces the features and characteristics of MAX105/MAX107 evaluation kit.
The document describes the Maxim MAX105 Evaluation Kit (EV kit), a fully assembled and tested circuit board designed to evaluate the performance of the MAX105 or MAX107 dual channel, 6-bit high-speed analog-to-digital converters. The kit includes the MAX105 ADC installed and allows users to evaluate the device with either differential or single-ended analog inputs.
| ADC Resolution | 6-bit |
|---|---|
| Max Clock Frequency | 800MHz |
| Input Signal Range | 0.8Vp-p |
| Digital Power Supply | +3.3V |
The kit evaluates the MAX105 or the MAX107 by replacing the installed chip.
The HP16500C series with the HP16517A 1.25Gbps state module is recommended.
The typical clock frequency should be 800MHz for the MAX105.
