The 74F199 is an 8-bit Parallel Access Shift Register. It has buffered clock and control inputs, shift right and parallel load capability, fully synchronous data transfers, J-K(D) inputs to first stage, clock enable for hold (do nothing) mode and asynchronous Master Reset.
The Philips 74F199 is an 8-bit parallel-access shift register designed for high-speed data transfers. It supports both serial and parallel data operations, including shift right, parallel load, and serial-to-parallel conversions. The device features buffered clock and control inputs, J-K type inputs for the first stage, and an asynchronous master reset.
| Operating temperature range | 0 to +70 °C |
|---|---|
| Number of bits | 8-bit |
The device operates in shift right, parallel load, and hold modes, controlled by the Parallel Enable input.
A Low signal on the Master Reset input overrides all other inputs and clears the register asynchronously.
