The CBT3126 is a quad FET bus switch that features independent line switches. Each switch is disabled when the associated Output Enable (OE) input is LOW.
The Philips CBT3126 is a quadruple FET bus switch designed with four independent line switches. Each switch can be disabled by pulling its associated Output Enable (OE) input LOW. The device supports standard 126-type pinouts in various packages, including SO-14, SSOP-14/16, and TSSOP-14.
| Product Type | Quadruple FET bus switch |
|---|---|
| Supply Voltage Range (Voc) | -0.5 to 7 V |
| Continuous Channel Current | 128 mA |
| Operating Ambient Temperature (Tamb) | -40 to +85 °C |
| On-resistance (Voc = 4.5 V, I=15mA) | 10 to 15 Ω |
| Propagation Delay (tpd) | Max 0.25 ns |
Each switch is disabled when the associated Output Enable (OE) input is LOW.
The recommended supply voltage range is 4.5 V to 5.5 V.
