lm7372 is a dual operational amplifier that offers high slew rate, low power consumption and wide gain bandwidth product. it is ideal for video and high speed signal processing applications
The LM7372 is a high speed dual voltage feedback amplifier designed for video and high speed signal processing applications such as xDSL. It combines the slewing characteristic of current feedback amplifiers with the stability of traditional voltage feedback configurations, operating stably at gains as low as +2 or -1.
Key features include a very high slew rate of 3000V/us, a wide gain bandwidth product of 120MHz, and a high output current of 150mA. The device is specified for both +15V operation to allow large signal swings and +5V operation for portable applications.
| Slew Rate | 3000V/us (typical at +15V) |
|---|---|
| Gain Bandwidth Product | 120MHz |
| Output Current | 150mA |
| Supply Current (both amps) | 6.5mA per amplifier / 13mA total |
| Unity Bandwidth Product (+5V) | 100 MHz |
Yes, it is stable for gains as low as +2 or -1.
Yes, the device is specified for +5V operation to support portable applications.
