lm76 temperature sensor has ±0.5˚c, ±1˚c, 12-bit + sign digital temperature sensor and thermal window comparator with two-wire interface
The document describes the LM760 as a differential voltage comparator offering speed improvements over the LM710 family. It operates from symmetric supplies of +4.5V to +6.5V and features complementary TTL-compatible outputs with guaranteed high-speed response times of 25 ns.
Key specifications include an input offset voltage minimum of 1.0 mV, a maximum differential input voltage of ±5.0 V, and operating temperature ranges from -55°C to +125°C for military grade devices. The datasheet provides typical performance characteristics graphs, application circuits such as zero crossing detectors and A/D converters, and physical dimensions for various package types including Metal Can, Ceramic DIP, and Molded DIP.
| Response Time | 25 ns |
|---|---|
| Supply Voltage Range | +4.5V to +6.5V |
| Operating Temperature Range (Military) | -55°C to +125°C |
| Output Resistance | 100 Ω |
The device offers a guaranteed high speed with a 25 ns response time.
The LM760 operates from symmetric supplies of +4.5V to +6.5V.
Yes, the outputs are TTL compatible with a minimum sink capability of two gate loads.
