The LM748 is a general purpose operational amplifier with external frequency compensation. The unity-gain compensation specified makes the circuit stable for all feedback configurations, even with capacitive loads. It is possible to optimize compensation for best high frequency performance at any gain. As a comparator, the output can be clamped at any desired level to make it compatible with logic circuits.
The LM748 is a general-purpose operational amplifier designed for operation from +5V to +20V. It features unity-gain compensation, making it stable for all feedback configurations, and includes continuous short-circuit protection. The device is compatible with logic circuits and operates as a comparator with differential inputs as high as +30V.
| Supply Voltage Range | +5V to +20V |
|---|---|
| Operating Temperature Range (LM748C) | 0°C to +70°C |
| Input Offset Voltage (Typ) | 5.0 mV |
| Supply Current (Typ) | 2.8 mA |
| Large Signal Voltage Gain | 160 V/mV |
| Order Number | LM748CN |
The device operates from +5V to +20V.
Yes, it features continuous short-circuit protection.
Yes, it can operate as a comparator with differential inputs as high as +30V.
