This document introduces the wireless and wired systems produced by Samson Technologies Corp., as well as the setup and usage of the Stage 55 Series/Stage 5 Series system. The document provides detailed information on the front and rear panels of the products and their respective functions. It also includes the technical specifications and features of the products.
This document is the user manual for the Samson Stage 55 Series and Stage 5 Series wireless systems. It provides a guided tour of the SR55, SRS, STS, ST5, and HTS components, explaining their front and rear panel features. The text details the system's operation within the 174.6 - 213.2 MHz frequency range and describes the differences between the non-diversity Stage 5 receiver and the diversity-equipped Stage 55 receiver.
| Frequency Range | 174.6 - 213.2 MHz |
|---|---|
| Power Input | 12 volt, 250 mA |
| Balanced Output Impedance | 600 Ohm |
Connect the supplied 12 volt, 250 mA power adapter to the DC input jack, ensuring the wire loop is passed through the strain relief to create a knot.
The system operates in the 174.6 - 213.2 MHz frequency range.
You must use the supplied 12 volt, 250 mA power adapter.
The switch sets the attenuation to -20 dBm (line level) or -40 dBm (mic level).
