MDR10 is a ten-channel mixer with ten low-noise microphone pre-amps, four output buses and a built-in 24-bit DSP effects processor.
The Samson MDR10 is a ten-channel mixer designed for recording, live sound reinforcement, and commercial installations. It features six mono Mic/Line input channel strips with three-band equalization and two stereo/dual-mono inputs. The unit includes an on-board 24-bit DSP effects processor with eight presets including Reverb, Delay, and Chorus.
| Channels | Ten channels (Six Mic/Line plus two Stereo/Dual inputs) |
|---|---|
| Frequency Response Mic to Main | -10 Hz - 30 kHz |
| T.H.D. Mic/Line to Main (Mono Ch) | 0.02% |
| Equivalent Input Noise | -128 dB |
| Maximum Voltage Gain Mic to Main | 74 dB |
| Phantom Power | +48V |
| Power Requirement | 110V-240V, 50/60Hz |
| Dimensions (W x Dx H) | 16.25" x 16.25" x 3.75" |
| Weight | 7.5 Ibs. |
The maximum voltage gain for the microphone input is 74 dB.
The frequency response for the line input to the main output is 10 Hz to 30 kHz.
The dimensions of the mixer are 16.25 inches by 16.25 inches by 3.75 inches.
