The document describes that the Dionex Chromeleon® 6.80 control software with service pack 3 and driver update 2c is able to fully support an Agilent 1200 Series Rapid Resolution LC (RRLC) system, except for some special functions. After installing the Chromeleon software and respective drivers, the Agilent 1200 Series RRLC system can be easily installed and configured, supports all important module parameters, evaluates raw data, including three-dimensional (3D) and two-dimensional (2D) data and spectra from Agilent ultraviolet (UV) detectors, supports maintenance and diagnostics with the Agilent Lab Monitor & Diagnostic software, can be quickly accessed using the Agilent 1200 Series instant pilot handheld controller, and executes some basic diagnostic/maintenance tasks from within Chromeleon.
This document describes the extent to which Dionex Chromeleon 6.80 control software with service pack 3 supports the Agilent 1200 Series Rapid Resolution LC (RRLC) system. It lists specific supported modules, such as pumps, autosamplers, and detectors, while noting that certain diagnostic features like pump pressure and leak tests are not supported within Chromeleon.
| Software Version | Dionex Chromeleon 6.80 with service pack 3 |
|---|---|
| Driver Update | driver update 2c |
| Firmware Version | B.0 lx or A.06xx |
| Controller Model | G4208A |
| Pump Model | G1310A |
| Autosampler Model | G1313A |
| Detector Model | G1314A |
It is able to fully support the system, except for some special functions.
No, diagnostics are supported except for pump diagnostics such as pressure and leak tests.
It allows quick access to the system to check parameters, status, and error messages, or to switch off the pump if the control software is down.
