The 709-DS Dissolution Apparatus uses the same platform as the 708-DS, ensuring productivity, reproducibility and ease of use combined with the convenience of a bath-free design. The 709-DS reduces media heating time with Direct Vessel Heating (DVH) capabilities while insulating the vessel from environmental factors and eliminating water bath cleaning. The exclusive design of the DVH ensures that the temperature inside the vessel is constant, eliminating temperature drift. The 709-DS uses an advanced electronic control system to precisely control the temperature and speed of the solution, ensuring the accuracy of the test results. The 709-DS is equipped with an intuitive touch screen for easy operation and setup.
The Agilent 709-DS Dissolution Apparatus is designed to ensure productivity, reproducibility, and ease of use. It utilizes a unique bath-free design with Direct Vessel Heating (DVH) technology to reduce media heating time while insulating the vessel from environmental factors.
Key features include an exclusive DVH TruAlign vessel incorporating heat-sensing technology in the vessel wall and a clear vessel coating for visibility and durability. The apparatus is compatible with optional features such as the Dosage Delivery Module (DDM), Autosampling, handheld temperature probes, and printers.
| Evaporative loss | Less than 1% |
|---|---|
| Ambient temperature range | 16 to 36 °C |
| Humidity limit | Not more than 80% RH |
| Voltage operating range | 90-250 V, 50-60 Hz |
| Temperature Range | Ambient +5 to 55°C |
| Spindle Speed Range | 10-250 RPM |
| Speed Accuracy | +1% over 25 RPM |
| Weight | 54.4 kg (120 Ib) |
It features a bath-free design that reduces media heating time and eliminates water bath cleaning.
Available options include the Dosage Delivery Module, Autosampling, handheld temperature probe, and printer.
