The Agilent Technologies SS420x Instrument Interface is an intelligent 24-bit analog to digital conversion module that provides remote acquisition for up to 4 channels of data. Designed for laboratory use, the SS420x can work with any type of analog-signal generating chromatography detector.
The Agilent SS420x High Resolution Chromatography Acquisition Module is an intelligent 24-bit analog to digital conversion module designed for laboratory use. It provides remote acquisition for up to four channels of data from any type of analog-signal generating chromatography detector. The module features asynchronous acquisition, four built-in triggers, and eight relays for programmable switching applications.
| Channels | Up to 4 |
|---|---|
| Dynamic Range | >1,000,000 : 1 |
| Input Signal Range | -5 to +11 Volt |
| Maximum Input Voltage (Continuous) | +45V |
| Common Mode Rejection Ratio | 96dB min. (1V range) |
| Normal Mode Rejection Ratio | 100dB min. |
| Monotonicity | 20 bits |
| Noise | 2uV RMS |
| Dimensions | 4.75" (121 mm) H x 9" (228 mm) L x 2.75" (70 mm) W |
The SS420x supports acquisition from up to four analog channels.
Data acquisition rates range from 0.1 Hz to 120 Hz depending on the base frequency used.
