SAA3010 is an infrared remote control transmitter with features such as low voltage requirement, biphase transmission technique, and single pin oscillator.
The Philips SAA3010 is a general-purpose infrared remote control transmitter designed for use with low voltage supplies and large debounce times. It utilizes a biphase transmission technique and features a single-pin oscillator to generate up to 2048 different commands for addressing 32 systems.
| Supply voltage range | 2 - 7 V |
|---|---|
| Operating ambient temperature range | -25 to +85 °C |
| Maximum input current | +10 mA |
| Maximum output current | +10 mA |
| Package type | 28-lead DIL plastic or 28-lead mini-pack |
The device utilizes a biphase transmission technique.
The device can generate 2048 different commands.
The maximum permissible temperature of the solder is 260 °C.
