The SAA4951 is a memory controller designed by Philips for high-end TVs using 2fH technology. The circuit provides all necessary write, read and clock pulses to control different field memory concepts. Furthermore, the drive signals for the horizontal and vertical deflection power stages are generated. The device is connected to a microcontroller via an 8-bit data bus. The controller receives commands via the I2C bus. Due to this fact the start and stop conditions of the main output control signals are programmable and the SAA4951 can be set in different function modes depending on the used TV-feature concept.
The Philips SAA4951 is a memory controller designed for high-end TV sets using 2f-technics. It provides all necessary write, read, and clock pulses to control different field memory concepts and generates drive signals for horizontal and vertical deflection power stages. The device is connected to a microcontroller via an 8-bit data bus and the 2C-bus, allowing programmable start and stop conditions for output control signals.
| Supply Voltage | 4.5 to 5.5 V |
|---|---|
| Operating Temperature | 0 to +70 °C |
| Supply Current | 50 mA |
| Package Type | SOT187(0) |
| Pin Count | 44 |
It is designed for high end TV sets using 2f-technics.
It is connected via an 8-bit data bus and the 2C-bus.
The supply voltage ranges from 4.5 V to 5.5 V.
