The SAA4963 is an alignment-free one chip comb filter compatible with NTSC M systems.
The Philips SAA4963 is an integrated circuit designed as an alignment-free one-chip comb filter compatible with NTSC M systems. It features time-discrete but continuous amplitude signal processing with analog interfaces, utilizing internal delay lines, filters, clock processing, and signal switches. The device requires few external components to operate effectively.
| CVBS Input Signal | 0.7 to 1.4 V peak-to-peak |
|---|---|
| Luminance Output Signal | 0.6 to 1.54 V peak-to-peak |
| Package Type | DIP20 or SOT163-1 |
The SAA4963 is compatible with NTSC M systems.
No, it is an alignment-free one-chip comb filter.
In SVHS mode, no IC function is active, and all clocks are inactive.
