The TJA1020 LIN transceiver is a low power, high performance interface for Local Interconnect Network (LIN). It supports baud rates up to 20 kbit/s. The device includes an integrated termination resistor for connection from either 3.3 V or 5 V devices. The TJA1020 also features a low slope mode for further reduction of EME.
The Philips TJA1020 is a LIN (Local Interconnect Network) transceiver designed as the interface between a master/slave protocol controller and the physical bus. It supports baud rates up to 20 Kbaud and is optimized for automotive sub-networks with controlled slew rate wave shaping to minimize electromagnetic emission.
| Baud rate | up to 20 Kbaud |
|---|---|
| Supply voltage (BAT) | 5 V to 12 V |
| Sleep mode current | 1 mA to 8 mA |
| Operating temperature range | -40 °C to +150 °C |
The device supports baud rates up to 20 Kbaud.
The supply voltage on pin BAT ranges from a minimum of 5 V to a maximum of 27 V.
The virtual junction temperature operates between -40 and +150 °C.
