This manual provides you with the necessary information of the operation and maintenance of your new IDEAL Fiber Inspection Microscope
The IDEAL 45-332 Fiber Inspection Microscope is designed to provide years of service with true optical performance. It can be configured for either 100x or 200x magnification depending on the eyepiece used (10x or 20x). The instrument comes fully assembled and includes a universal 2.5mm connector adapter, with various other interchangeable adapters available for purchase.
| Magnification | 100x or 200x depending on eyepiece used (10x or 20x) |
|---|---|
| Included Adapter | Universal 2.5mm connector adapter (Part #693.008) |
| Battery Type | Three type "LR44" batteries |
Unscrew the Universal Adapter from the microscope and replace it with another. The instrument comes fully assembled, but other adapters may be used if needed.
Remove the battery cap and the three used batteries, then replace them with three type "LR44" batteries before replacing the cap.
