The DS9003 Cartridge Proto Board is a developmental printed circuit board for prototyping portable hand-held cartridges. The gold-plated card edge connections conform to the popular 28-pin bytewide DIP socket pinout when used with the DS9000 Bytewide Cable Harness. The card profile matches that of the DS1217 Nonvolatile Read/Write Cartridges and can be used with the NO TAG Cartridge Housing. It features a plated through-hole pattern for wire wrap or solder mount development. It allows for a single double-size cartridge or two standard-size cartridges. It has separate full length power and ground buses for ease of layout.
The DS9003 Cartridge Proto Board is a developmental printed circuit board designed for prototyping portable hand-held cartridges. It features gold-plated card edge connections that conform to the popular 28-pin bytewide DIP socket pinout when used with the DS9000 Bytewide Cable Harness.
| Compatible Cartridge Profile | Matches profile of DS1217 Nonvolatile Read/Write Cartridges |
|---|---|
| Connection Type | 28-pin bytewide DIP socket pinout |
| Card Edge Plating | Gold-plated card edge fingers |
It is a developmental printed circuit board used for prototyping portable hand-held cartridges.
The card profile matches that of the DS1217 Nonvolatile Read/Write Cartridges.
It allows for a single double-size cartridge or two standard-size cartridges.
