The COP402/COP402M are members of the COPS™ family of N-channel silicon gate MOS technology. These devices function as exact circuit equivalents to the COP420 but with the ROM removed, allowing for external PROM or ROM interfacing. The COP402M variant includes a MICROBUS interface option.
| Operating Temperature Range | 0°C to 70°C |
|---|---|
| Storage Temperature Range | -65°C to +150°C |
| RAM Size | 64 x 4 bits |
| ROM Addressing Capacity | up to 1k x 8 |
| Operating Voltage | 4.5V to 6.3V |
| Instruction Cycle Time | 4 ps (typical) |
| Operating Clock Frequency | up to 16 MHz |
The device comes in a standard 40-pin dual-in-line package.
The maximum power supply voltage is 6.3 V.
