The ADS1610 is a high-speed, high-precision, delta-sigma (ΔΣ) analog-to-digital converter (ADC) with 16-bit resolution. It features a high-speed, wide bandwidth with a 10MSPS output data rate, 4.9MHz signal bandwidth, 86dBFS signal-to-noise ratio, -94dB total harmonic distortion, and 95dB spurious-free dynamic range. The ADS1610 is suitable for applications in scientific instruments, test equipment, and communications.
The ADS1610 is a high-speed, high-precision, delta-sigma analog-to-digital converter (ADC) with 16-bit resolution. It operates from a +5V analog and a +3V digital supply and features an advanced multi-stage analog modulator combined with an on-chip digital decimation filter. The device achieves an 86dBFS signal-to-noise ratio in a 5MHz signal bandwidth and offers outstanding performance with a total harmonic distortion of -94dB.
| Resolution | 16 Bits |
|---|---|
| Output Data Rate | 10 MSPS |
| Signal Bandwidth | 4.9 MHz |
| Signal-to-Noise Ratio | 86 dBFS |
| Total Harmonic Distortion | -94 dB |
| Spurious-Free Dynamic Range | 95 dB |
| Operating Temperature Range | -40 to +85 °C |
| Package Type | TQFP-64 |
The ADS1610 provides a 10 MSPS output data rate.
The device operates from a +5V analog supply and a +3V digital supply.
Yes, it is pin-compatible with the ADS1605 (5MSPS ADC).
