The document describes the features and characteristics of the 74HC/HCT10 triple 3-input NAND gate. They are high-speed Si-gate CMOS devices and are pin compatible with low power Schottky TTL (LSTTL). The device provides the 3-input NAND function.
This datasheet describes the 74HC/HCT10, a high-speed Si-gate CMOS integrated circuit that provides the 3-input NAND function. The device is pin compatible with low power Schottky TTL (LSTTL) and is specified in compliance with JEDEC standard no. 7A.
The document details the electrical characteristics, including propagation delay, input capacitance, and power dissipation capacitance for both 74HC and 74HCT variants across various operating temperatures. It also includes pin descriptions, a functional table, and references to package information and family specifications.
| Logic Function | Triple 3-input NAND gate |
|---|---|
| Technology | High-speed Si-gate CMOS |
| TTL Compatibility | Pin compatible with LSTTL |
| Propagation Delay (Typical) | 9 ns |
| Input Capacitance | 3.5 pF |
| Power Dissipation Capacitance | 12 pF |
| IC Category | SSI |
The device provides the 3-input NAND function.
Yes, it is pin compatible with low power Schottky TTL (LSTTL).
The typical propagation delay is 9 ns under standard conditions.
