The DAC0800/DAC0802 8-bit digital-to-analog converters are high-performance, high-precision DACs produced by Texas Instruments, with a typical settling time of 100 ns and a maximum output current of ±18V, which can be used for measurement, control and other applications
The DAC0800 and DAC0802 are monolithic 8-bit high-speed current-output digital-to-analog converters (DAC) designed as direct replacements for the DAC-08 series. They feature typical settling times of 100 ns and monotonic performance over a 40 to 1 reference current range. The devices offer high compliance complementary current outputs, allowing differential output voltages of 20 Vp-p with simple resistor loads.
| Resolution | 8 Bits |
|---|---|
| Nonlinearity | +0.1% FS |
| Settling Time | 100 ns |
| Power Supply Range | +4.5V to +18V |
| Power Dissipation | 33 mW |
| Output Voltage Compliance | -10V to +18V |
The typical settling time is 100 ns.
The full scale error is +1 LSB.
The nonlinearity over temperature is +0.1%.
Yes, the noise immune inputs will accept TTL levels with the logic threshold pin grounded.
