The DAC0890 is a complete dual 8-bit voltage output digital-to-analog converter that can operate on a single 5V supply. It includes on-chip output amplifiers, precision bandgap voltage reference, and full microprocessor interface. Each DAC0890 output amplifier has two externally selectable output ranges, 0V to 2.55V and 0V to 10.2V. The amplifiers are internally trimmed for offset and full-scale accuracy and therefore require no external user trims. The DAC0890 is supplied in a 20-pin ceramic DIP package.
The DAC0890 is a complete dual 8-bit voltage output digital-to-analog converter designed to operate on a single 5V supply. It features on-chip output amplifiers, a precision bandgap voltage reference, and a full microprocessor interface, eliminating the need for external user trims. The device is supplied in a 20-pin ceramic DIP package.
| Resolution | 8 Bits(min) |
|---|---|
| Monotonicity | 8 Bit(min) |
| Integral Linearity Error | +/-0.16 LSB(min) |
| Zero Error | +/-1.0/+2.0 LSB(max) |
No, the output amplifiers are internally trimmed for offset and full-scale accuracy, requiring no external user trims.
The DAC0890 provides a resolution of 8 bits minimum.
