LM101A/LM201A/LM301A operational amplifiers are general purpose operational amplifiers with high performance, high precision, low noise, low input current and low bias current.
The document describes the LM101A series of general-purpose operational amplifiers, which feature improved performance over industry standards like the LM709. Key improvements include an order of magnitude reduction in input currents and reduced temperature drift for input current. The devices offer features such as overload protection on inputs and outputs, no latch-up when common mode range is exceeded, and freedom from oscillations with a single 30pF capacitor.
| Offset Voltage (LM101A/LM201A) | 3 mV maximum over temperature |
|---|---|
| Input Current (LM101A/LM201A) | 100 nA maximum over temperature |
| Offset Current (LM101A/LM201A) | 20 nA maximum over temperature |
| Slew Rate (Summing Amplifier) | 10V/µs |
| Supply Voltage Range (LM101A/LM201A) | ±22V |
| Operating Ambient Temp. Range (LM101A) | -55˚C to +125˚C |
| Operating Ambient Temp. Range (LM301A) | 0˚C to +70˚C |
The maximum offset voltage over temperature is 3 mV.
LM101A is -55˚C to +125˚C, LM201A is -25˚C to +85˚C, and LM301A is 0˚C to +70˚C.
No, it is freedom from oscillations with a single 30pF capacitor.
