Actel eX Family FPGAs are low-cost solutions for low-power, high-performance designs. The inherent low power attributes of the antifuse technology, coupled with an additional low static power mode, make these devices ideal for applications requiring low power and high performance
The Actel eX Family FPGAs are a low-cost solution designed for low-power, high-performance designs. Fabricated with an advanced 0.22 CMOS antifuse technology, these devices achieve high performance without power penalties. The architecture utilizes a 'sea-of-modules' structure where the entire floor is covered with a grid of logic modules, including register cells (R-cells) and combinatorial cells (C-cells), interconnected via patented metal-to-metal programmable antifuses.
| System Gates (Capacity) | 3,000 to 12,000 |
|---|---|
| Maximum Flip-Flops | 512 |
| Process Technology | 0.22 CMOS |
| Maximum User I/O Pins | 132 |
| System Performance Frequency | 240 MHz |
| Clock-to-Out (Pad-to-Pad) | 3.9ns |
| Internal Performance Frequency | 350 MHz |
The devices are fabricated with an advanced 0.22 CMOS antifuse technology.
Yes, all I/Os are tristated during power up/down to prevent damage or system degradation.
Up to 512 maximum flip-flops are available when using CC Macros.
