This document is the NS-BP100/NS-BP110 speaker user manual, introducing the features and usage methods of the speaker
The document serves as an owner's manual for the Yamaha NS-BP100 and NS-BP110 two-way bass-reflex speaker systems. It covers essential precautions regarding placement, such as avoiding heat sources and direct sunlight, and warns against inserting hands into ports to prevent injury or damage.
The guide details how to attach the front cover and install optional stands on the NS-BP110 model using 4mm screws. It also explains the connection process to a receiver, emphasizing that the receiver must be switched off before making connections.
| System Type | 2-way bass-reflex speaker system |
|---|---|
| Shielding Type | Non-magnetic shielding |
| Woofer Driver | 10 cm (4") cone woofer |
| Tweeter Driver | 2.5 cm (1") balanced dome tweeter |
| Frequency Response | 60 Hz to 50 kHz (-10 dB) |
| Dimensions (NS-BP100) | 123 x 192 x 294 mm |
| Dimensions (NS-BP110) | 123 x 192 x 296 mm |
| Weight (NS-BP100) | 2.1 kg |
| Weight (NS-BP110) | 2.3 kg |
A screw with a diameter of 4 mm can be used.
You may not obtain good bass quality when placed directly on the floor; it is recommended to put a block under them.
