The ACT-E128K32 is a high speed, 4 megabit, CMOS EEPROM multichip module (MCM) designed for full temperature range military, space, or high reliability applications.
The Aeroflex ACT-E128K32 is a high-performance, electrically erasable and programmable read-only memory (EEPROM) designed for full-temperature range military, space, or high-reliability applications. It consists of four 1-megabit memory chips organized as 128K x 32 bits.
| Memory Organization | 128K x 32 bits, configurable to 256K x 16 or 512K x 8 |
|---|---|
| Access Times | 120, 140, 150, 200, 250 & 300ns |
| Supply Voltage | +5V +10% |
| Page Write Cycle Time | 10ms Max |
| Data Retention | Ten Years Minimum |
| Operating Temperature Range | -55°C to +125°C |
The maximum page write cycle time is 10ms.
Yes, an optional software data protection mechanism is available to guard against inadvertent writes.
The device offers standard access times of 120, 140, 150, 200, 250 & 300ns.
