The IDT70V07S/L is a high-speed 3.3V 32K x 8 dual-port static RAM from IDT. It features true dual-ported memory cells that allow simultaneous access of the same memory location. It also features high-speed access and low power consumption. The IDT70V07S/L can be cascaded with multiple devices to expand the data bus width to 16 bits or more using the Master/Slave select.
The IDT70V07 is a high-speed, 32K x 8 Dual-Port Static RAM designed for commercial temperature ranges. It features true dual-ported memory cells that allow simultaneous access to the same memory location from two independent ports with separate control and address pins.
Available in S (standard) and L (low-power) versions, the device operates on a single 3.3V power supply and is fabricated using CMOS high-performance technology. It supports asynchronous operation from either port and includes features such as busy flags, interrupt flags, and on-chip port arbitration logic for semaphore signaling.
| Memory Configuration | 32K x 8 Dual-Port Static RAM |
|---|---|
| Supply Voltage | 3.3V (+0.3V) |
| Operating Temperature Range (Commercial) | 0°C to +70°C |
| Active Power Consumption (Typ.) | 450mW |
| Standby Power Consumption (Typ.) | 5mW |
| Access Time (Commercial) | 25/35/55ns max. |
| Package Types | 68-pin PGA, 68-pin PLCC, 64-pin TQFP |
Yes, it can expand data bus width to 16 bits or more by cascading multiple devices using the Master/Slave select.
Yes, it features full on-chip hardware support of semaphore signaling between ports.
