IAM48 is the second generation DC input front-end, designed to occupy minimum board space while providing maximum transient protection for today's sophisticated electrical systems. IAM48, in combination with Vicor's 48V input 2nd Generation DC-DC converters, provides comprehensive protection, including surge, transient and reverse polarity protection.
The Vicor IAM48 is a component-level, DC input front-end module designed to provide inrush current limiting and input transient protection for 48V input DC-DC converters. It is engineered to occupy minimum board space while offering maximum transient protection for sophisticated electrical systems. When used in combination with Vicor's FM-48 filter module, the system meets conducted EMI specifications for Telcordia, FCC, and European Norms.
| Input Voltage | 36Vdc to 76Vdc |
|---|---|
| Efficiency | 97% |
| Weight | 1.7 ounces (50 grams) |
| Warranty | 2 years |
| Operating Temperature (C-Grade) | -20 to +100 °C |
| Storage Temperature | -40 to +125 °C |
The module has UL 1950, CSA 22.2-950, and EN 60950 safety approvals.
No, the module provides reverse polarity protection without requiring an external fuse.
The internal voltage drop is a maximum of 1.1V at 20A and 100°C baseplate.
