About this manual

The document describes the LT1057 as a matched JFET input dual op amp in an industry standard 8-pin configuration, featuring high speed and precision specifications. It replaces popular bipolar and JFET input dual op amps such as the LF412A and OP-215. The LT1058 is described as the lowest offset quad JFET input operational amplifier in a standard 14-pin configuration.

What's inside

Features
Applications
Absolute Maximum Ratings
Package/Order Information
Electrical Characteristics
Typical Performance Characteristics

Specifications

Slew Rate (Min)	14 V/us
Gain-Bandwidth Product	5MHz
Input Offset Voltage (LT1057) Typ	150uV
Input Bias Current (Typ)	+5 pA

Frequently asked questions

What is the minimum slew rate of these op amps?

The device features a minimum slew rate of 14V/us.

What is the maximum input offset voltage for the LT1058 model?

The LT1058 has a maximum input offset voltage of 600uV.

What is the operating temperature range for the LT1057AC and LT1058AC packages?

These specific packages operate within a temperature range of 0°C to 70°C.
