The LTC1591/LTC1597 are pin compatible, parallel input 14-bit and 16-bit multiplying current output DACs that operate from a single 5V supply. INL and DNL are accurate to 1LSB over the industrial temperature range in both 2- and 4- quadrant multiplying modes. True 16-bit 4-quadrant multiplication is achieved with on-chip 4-quadrant multiplication resistors. These DACs include an internal deglitcher circuit that reduces the glitch impulse to less than 2nV-s (typ). The asynchronous CLR pin resets the LTC1591/LTC1597 to zero scale and LTC1591-1/LTC1597-1 to midscale. The LTC1591/LTC1597 are available in 28-pin SSOP and PDIP packages and are specified over the industrial temperature range. For serial interface 16-bit current output DACs refer to the LTC1595/LTC1596 data sheet.
The LTC1591 and LTC1597 are pin-compatible, parallel-input multiplying current output DACs that operate from a single +5V supply. They feature true 16-bit performance over the industrial temperature range in both 2- and 4-quadrant multiplying modes, achieved with on-chip 4-quadrant multiplication resistors.
These devices include an internal deglitcher circuit that reduces the glitch impulse to less than 2 nV-s (typical). They are available in 28-pin SSOP and PDIP packages. The datasheet provides absolute maximum ratings, electrical characteristics including accuracy and AC performance, typical application circuits, and detailed performance graphs.
| Resolution | 14-bit or 16-bit |
|---|---|
| Differential Nonlinearity (DNL) | +1 to -0.2 LSB (typical) |
| Midscale Glitch Impulse | < 2 nV-s (typical) |
| Output Current Settling Time | 1 us |
The internal deglitcher circuit reduces the glitch impulse to less than 2 nV-s (typical).
The LTC1591/LTC1597 are available in 28-pin SSOP and PDIP packages.
