The ADF4360-3 is a fully integrated integer-N synthesizer and voltage controlled oscillator (VCO)
The ADF4360-3 is a fully integrated integer-N synthesizer and voltage controlled oscillator (VCO) designed for a center frequency of 1750 MHz. It features an output frequency range from 1600 MHz to 1950 MHz, with an optional divide-by-2 output providing frequencies between 800 MHz and 975 MHz. The device operates with a power supply ranging from 3.0 V to 3.6 V and includes a programmable dual-modulus prescaler.
| Output frequency range | 1600 MHz to 1950 MHz |
|---|---|
| Divide-by-2 output range | 800 MHz to 975 MHz |
| Power supply voltage | 3.0 V to 3.6 V |
| Logic compatibility | 1.8 V |
| Interface type | 3-wire serial interface |
| VCO Sensitivity | 45 MHz/V typ |
| Lock Time | 400 us typ |
The device operates from -40°C to +85°C.
Yes, it is an ESD sensitive device with a rating of <1 kV.
