This document provides the installation guide for the Agilent 7683 Automatic Liquid Sampler. The product is classified as Safety Class 1, Transient Overvoltage Category II, and Pollution Degree 2. The document also includes safety information and warnings.
The Agilent 7683 Automatic Liquid Sampler is designed to be installed on an Agilent 6890 Plus Gas Chromatograph. This document provides step-by-step instructions for unpacking, installing the ALS Interface Board (G2612A), the Injector Module (G2613A), and optional accessories like the Tray (G2614A) and Bar Code Reader (G1926A). It also details cabling connections and initial configuration steps.
| Safety Class | Class 1 |
|---|---|
| Transient Overvoltage Category | IL |
| Pollution Degree | 2 |
The sampler consists of the G2612A ALS Interface Board, the G2613A Injector Module, an optional G2614A Tray, and an optional G1926A Bar Code Reader.
The tray and ALS interface board are installed only on the 6890 Plus Gas Chromatograph (GC).
Ensure the connection to the GC is secure; if the error remains, obtain Agilent service.
