IC61LV2568 is a very high-speed, low power, 262,144-word by 8-bit COMS static RAM.
The IC61LV2568 is a 256K x 8 high-speed CMOS static RAM fabricated using ICSI’s high-performance CMOS technology. It operates from a single 3.3V power supply and features TTL-compatible inputs and outputs. Available in 36-pin SOJ and 44-pin TSOP-2 packages, it supports access times of 8, 10, 12, and 15 ns. The device includes power-down modes for reduced power consumption and multiple power and ground pins for noise immunity.
| Access Time | 8, 10, 12, 15 ns |
|---|---|
| Power Supply | 3.3V ±10% |
| Package | 36-pin SOJ, 44-pin TSOP-2 |
| Power Consumption | 540 mW @ 10 ns, 36 mW standby |
The device operates from a single 3.3V power supply.
It is available in 36-pin SOJ and 44-pin TSOP-2 packages.
The access times are 8, 10, 12, and 15 ns.
