About this manual

This document is a technical drawing for the Tyco Electronics part number 9-226176. It provides detailed views of the connector assembly, specifying acceptance criteria for coaxial cables with .095-.110 O.D. jackets and .055—.065 dielectric O.D., such as RG-174 and RG-316.

The document includes specific manufacturing instructions, noting that instruction sheet 408-2472-2 applies to the assembly. It details material requirements like brass per ASTM-B-36 and tin-lead plate per ASTM-B-545. Additionally, it provides a PCB layout diagram with hole specifications for installation.

What's inside

• Drawing Description
• Cable Acceptance Criteria
• Manufacturing Instructions
• Material Specifications
• PCB Layout

Frequently asked questions

What coaxial cable jacket and dielectric sizes does this connector assembly accept?

The assembly accepts coax cables with .095-.110 O.D. jackets and .055—.065 dielectric O.D., such as RG-174 and RG-316.

What is the part number for the instruction sheet included with this assembly?

The associated instruction sheet has the number 408-2472-2.

How must the legs of loose piece parts be prepared after crimping?

Legs on strip parts must be bent manually after crimping, while loose piece parts have preformed legs.
