The Osram LINEARIlight Flex Top Colormix is a flexible circuit board featuring self-adhesive backing that allows for convenient field cutting. Each individual LED package contains red, green, and blue chips to achieve an infinite choice of colors, including white, with superior consistency compared to separate colored LEDs. The modules are sold in 13.1 ft reels suitable for long linear runs and complex geometries.
| Module Size (LxW) | 13.1 ft x 0.45 in (4000mm x 11.5mm) |
|---|---|
| Smallest Unit Size | 7.9 in x 0.45 in (200mm x 11.5mm) |
| LED Spacing | 20mm |
| Operating Temperature | -30...+475°C (-22...+896°F) |
| Voltage Range | 23...25 Vdc |
The minimum bend radius is 2 cm.
Yes, modules may be subdivided into smaller coupons of 10 LEDs.
