The IXDN402/IXDI402/IXDF402 is a dual 2A CMOS high-speed MOSFET driver. It is built using the advantages and compatibility of CMOS and IXYS HDMOSTM processes. The driver features a wide operating range, high peak output current, low propagation delay time, and is suitable for driving MOSFETs and IGBTs, motor controls, line drivers, etc.
The IXDN402/IXDI402/IXDF402 family consists of two 2 Amp CMOS high speed MOSFET drivers. Each output can source and sink 2A of peak current while producing voltage rise and fall times of less than 15ns to drive the latest IXYS MOSFETs & IGBTs.
The input of the driver is TTL or CMOS compatible and is fully immune to latch up over the entire operating range. A patent-pending circuit virtually eliminates cross conduction and current shoot-through.
| Peak Output Current | 2A Peak |
|---|---|
| Operating Temperature Range | -40 °C to +85 °C |
| Junction Temperature | 150 °C |
| Output Resistance (High) | 3.7 Ohms |
The device provides a high peak output current of 2A.
Yes, the input is TTL or CMOS compatible and fully immune to latch up.
The family is available in 8 pin PDIP, SOP-8 (SI), and SOP-16 (SI-16) packages.
