This document describes an integrated single-package solution including a high-performance HC08 microcontroller with a SMARTMOSTM analog control IC. It features Flash Memory, a timer, Enhanced Serial Communications Interface (ESCI), an Analog-to-Digital Converter (ADC), Serial Peripheral Interface (SPI), and an Internal Clock Generator (ICG) module. Additionally, it includes fully protected H-Bridge/high-side outputs, voltage regulator, autonomous watchdog with cyclic wake-up, and Local Interconnect Network (LIN) physical layer. The single-package solution, together with LIN, provides optimal application performance adjustments and space-saving PCB design, making it well suited for the control of automotive mirror, door lock, and light-levelling applications.
The 908E425 is an integrated single-package solution that combines a high-performance M68HC908EY16 core microcontroller with a SMARTMOS™ analog control IC. This integration provides optimal application performance and space-saving PCB design, making it well-suited for controlling automotive mirrors, door locks, and light-leveling applications.
The device features an embedded MCU with 16K Bytes of Flash Memory, internal clock generation, and enhanced serial communications. The integrated analog die includes fully protected H-Bridge/high-side outputs, a voltage regulator, an autonomous watchdog with cyclic wake-up, and the Local Interconnect Network (LIN) physical layer.
| Flash Memory | 16K Bytes |
|---|---|
| RAM | 512 Bytes |
| Package Type | 54-PIN SOICWB-EP |
| Microcontroller Core | M68HC908EY16 |
It is well suited for controlling automotive mirror, door lock, and light-leveling applications.
Yes, the analog control die provides the Local Interconnect Network (LIN) physical layer.
