The PC8171X NSZ Series is a photocoupler from Omron. Its main features are low input current (IF=0.5mA), high resistance to noise (CMR: MIN. 10kV/µs), compact dual-in line package and recognition by UL (file No. E64380).
The PC8171xNSZ series is a low‑input‑current (IF = 0.5 mA) photocoupler with high common‑mode rejection and a compact dual‑in‑line package. It is intended for use in programmable controllers, facsimiles, and telephones.
The datasheet lists absolute maximum ratings, electro‑optical characteristics, and a range of performance graphs such as forward voltage, isolation resistance, and response time. Soldering recommendations and temperature limits are also included.
| Input forward current (IF) | 0.5 mA |
|---|---|
| Isolation voltage (Viso) | 5 kV |
| Forward voltage (VF) at 10 mA | 1.2 V – 1.4 V |
| Collector current (Ic) | 50 mA |
| Operating temperature range | -30 °C to +100 °C |
| Maximum forward current | 10 mA |
The typical input forward current is 0.5 mA.
It is rated for an isolation voltage of 5 kV.
Typical applications include programmable controllers, facsimiles, and telephones.
The maximum collector current is 50 mA.
