BD3813KS/BD3815KS is a 5.1-channel audio processor from ROHM that integrates an amplifier and volume/bass/treble controls, making it ideal for use in audio applications such as AV receivers, home theater systems, and mini-component systems.
The BD3813KS and BD3815KS are semiconductor sound processors designed for AV receivers, home theater and mini‑component systems. They integrate a gain amplifier and independent volume, bass and treble controls, enabling 6.1‑ch or 7.1‑ch operation when used with the BD3812F volume IC.
Key features include a 129 dB dynamic range, low current consumption, a maximum output of 4.2 Vrms, and a 2‑wire serial control interface. The devices are supplied in an SQFP56 package and operate from a ±7 V supply.
| Dynamic range | 129 dB |
|---|---|
| Maximum output voltage | 4.2 Vrms |
| Package | SQFP56 |
| Power supply voltage | VCC = 7 V, VEE = ‑7 V |
| Operating temperature range | -20 °C to 75 °C |
| Volume control range | -95 dB |
The device provides a wide dynamic range of 129 dB.
The maximum output voltage is 4.2 Vrms.
Both parts are supplied in an SQFP56 package.
The devices operate from a +7 V VCC and a –7 V VEE supply.
