BD5444EFV is an analog input Class D speaker amplifier designed for flat-panel TVs, with features of space-saving and low power consumption, delivering an output power of 20W+20W.
The BD5444EFV is an analog‑input Class‑D speaker amplifier designed for flat‑panel TVs and other audio equipment. It delivers an output power of 20W+20W (stereo) or 40W mono bridge‑tied‑load, with a high efficiency of 93% at 10W+10W output into an 8 Ω load.
The device operates from a wide supply voltage (10 V to 27 V), offers four selectable gain settings (14, 20, 26, 32 dB), and includes protection functions such as over‑temperature, short‑circuit, and undervoltage. It is packaged in a compact HTSSOP‑B28 package and is intended for use in flat‑panel TVs, home audio, desktop PCs, and other consumer electronics.
| Output power (stereo) | 20W + 20W |
|---|---|
| Output power (mono BTL) | 40W |
| Supply voltage range | 10 V – 27 V |
| Selectable gain | 14, 20, 26, 32 dB |
| Package | HTSSOP‑B28 |
| Maximum supply voltage (absolute rating) | 30 V |
| Operating temperature range | -25 °C – +85 °C |
| Maximum junction temperature | +150 °C |
The absolute maximum supply voltage is 30 V.
It is supplied in an HTSSOP‑B28 surface‑mount package.
Four gain settings are selectable: 14 dB, 20 dB, 26 dB, and 32 dB.
