This document describes the features and characteristics of NTC thermistors and Flex Foil sensors, including rapid response time, suitability for narrow space applications, high flexibility of the foil, insulation and humidity resistance, etc. The product is suitable for consumer appliances, power supply, battery, display, industrial applications, and boilers.
The NTCAFLEX series are miniature NTC temperature sensors on a flexible foil substrate, designed for rapid response in narrow‑space applications. They are insulated, humidity‑resistant, and can be mounted by pressing, gluing, or screwing, with optional strain‑relief holes.
The sensors are available with optional FFC/FPC connectors (tin or gold plated) or without a connector. Detailed electrical parameters, mechanical dimensions, and ordering codes are provided for various resistance values and B‑temperature coefficients. This manual is written in Chinese.
| Resistance at 25 °C | 4.7 kΩ |
|---|---|
| Tolerance on R25 | ±3 % |
| B‑value (25 °C/85 °C) | 3960 K |
| Operating temperature range | -40 °C to 125 °C |
| Minimum dielectric withstanding voltage | 500 V AC |
| Weight (without connector) | 0.13 g |
The sensor has a resistance of 4.7 kΩ at 25 °C.
The sensor can be supplied with an FFC/FPC connector that is either tin‑plated, gold‑plated, or without a connector.
It operates from –40 °C up to 125 °C at zero power.
