74LVC07A is a 6-channel non-inverting buffer with 5V tolerant inputs and outputs (open drain), which can be interfaced with 5V logic. It has a wide supply voltage range of 1.65-5.5V, 1 mA input current, 100 MHz open drain output high end bandwidth, CMOS low power consumption, direct interface with TTL levels and compliance with JEDEC standard No. 8-1A.
The 74LVC07A is a high‑performance, low‑power hex buffer with open‑drain outputs, suitable for interfacing 3.3 V and 5 V logic levels. It offers six non‑inverting buffers and can be used as translators in mixed‑voltage environments.
Key features include a wide supply voltage range (1.65 V to 5.5 V), 5 V tolerant inputs and outputs, low propagation delay (~2 ns), and various package options such as SO‑14 and TSSOP‑14. Detailed electrical characteristics, pin assignments, and ordering information are provided in the document.
| Supply voltage range | 1.65 V to 5.5 V |
|---|---|
| Number of buffers | 6 non‑inverting buffers |
| Input tolerance | 5 V tolerant inputs |
| Output type | Open‑drain |
The device operates from 1.65 V up to 5.5 V.
It contains six non‑inverting buffers.
The outputs are open‑drain, allowing wired‑OR or wired‑AND configurations.
