This document describes how to install Axis blade video servers in the AXIS 291 1U Video Server Rack.
The installation guide covers hardware installation of the AXIS 291 1U Video Server Rack, which can hold up to three Axis blade video servers. It includes a hardware inventory, power‑cord variants, mounting kit components, and safety cautions such as the risk of electric shock.
Placement requirements, power specifications, and connector details are described. The rack must be installed in an environment with 0‑45 °C temperature, 20‑80 % relative humidity, a power source within 1.8 m, and at least 5 cm of clearance on each side. Power is supplied directly from an AC cord (no on/off switch) and the unit powers up automatically when the cord is connected.
| Input voltage | 100‑240 V AC, 50‑60 Hz |
|---|---|
| Input current | 1.9 A |
| Maximum power consumption (3 servers) | 80 W |
| Ambient temperature range | 0 °C to +45 °C |
| Relative humidity range | 20 % to 80 % |
| Maximum weight of rack with cables | 6 kg |
The rack can accommodate up to three Axis blade video servers.
