The KRA107S series planar PNP transistors from Korea Electronics are presented with key features such as built‑in bias resistors, simplified circuit design, and reduced part count. The sheet lists the device markings, package type (SOT‑83) and manufacturing details.
Electrical specifications include output voltage, input voltage ranges, current gain, maximum output current, power dissipation, junction temperature and storage temperature limits. Typical values for the KRA107S, KRA108S and KRA109S devices are provided in tabular form. This manual is written in Japanese.
| Power Dissipation | 200 mW |
|---|
The device can dissipate up to 200 mW.
