The TS94x series are low-voltage, low-power operational amplifiers designed for single-supply applications.
The TS941/TS942/TS944 family are low‑power, rail‑to‑rail output operational amplifiers designed for battery‑powered applications. They operate from a single supply of 2.5 V to 10 V and function over a temperature range of –40 °C to +85 °C.
The document provides absolute maximum ratings, detailed electrical characteristics, package dimensions, order codes and a summary of revisions. Typical specifications include a 10 kHz gain‑bandwidth product, 45 V/µs slew rate, 150 pA input bias current and output source/sink currents up to 650 µA per amplifier.
| Supply Voltage Range | 2.5 V to 10 V |
|---|---|
| Input Bias Current (typical) | 150 pA |
| Package Type | SOT23‑5 micropackage |
| Package Length (A) | 0.90 mm min / 1.45 mm max |
They operate from a single supply voltage of 2.5 V up to 10 V.
The typical input bias current is 150 pA.
They are available in an SOT23‑5 micropackage.
